AC Power Chassis Module Specifications
Dimension 7.64 in. (194mm) x 6.15 in. (156mm) x 1.59 in. (40.3mm)
Installation method Plug in to system rear panel
Maintenance Modular design for easy maintenance
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Power status indication Green LED Electric
Input voltage rating 100 ~ 240VAC
Input voltage range 90 ~ 264VAC
Input frequency 47 ~ 63Hz
Input surge current 20A max. @115VAC
Efficiency 75% @ 115VAC full load
Output power 60W
Over current protection All output with short circuit protection
Safety UL / cUL, TUV EN60950
Insulation Resistance >10M Ohm @ DC500V
Dielectric withstands 1500VAC 10mA 1min.
Management Module Specifications
Dimension 4.22 in. (107mm) x 0.95 in. (24mm) x 3.40 in. (86.4mm)
Slot position Slot 0
CPU RISC-based ARM7
RAM size 1M bytes
Flash size 512K bytes
System interface
Connector FutureBus connector
Console interface
Interface RS-232 DTE
Connector 9-pin male D-SUB connector
Baud rate 38400, N, 8, 1, 0
Flow control Disabled
In-band interface
Interface 10/100M LAN port
Connector Shielded RJ-45 MDI
Standard IEEE 802.3 10BASE-T/100BASE-TX
Auto-negotiation Support
LED Indicators
P1, P2 Green LED, power module status
DIAG Green LED, CPU initialization
FAN Green LED, Fan failure indication
CONSOLE Green LED, Console RS-232 Rx activities
LNK/ACT. Green LED, LAN port link and activities status
