EVX-539 OpErating Manual6
Belt Clip Installation and Removal
BEForE You BEgIn

To install the Belt Clip: align
the Belt Clip to the groove of
the Battery pack, then press
the Belt Clip downward until it
locks in place with a “Click.”
Belt Clip Tab

To remove the Belt Clip: use a
at head screw driver to press
the Belt Clip Tab away from
the battery pack to unlock the
Belt Clip, then slide the Belt
Clip upward to remove it.
MIC/SP CAP Installation
Install the
MIC/SP
cap with the
supplied screws.

Use only the supplied screws
when install the
MIC/SP
cap.

This radio does not keep the
submersible Rating (IP57: 1
meter / 30 minutes) when the
MIC/SP
cap is not installed
in the
MIC/SP
jack.
