TELCALL Operation
The VX-1210 allows easy “TELCALL” Operation for Autopatch
dialing.
When the “TELCALL” feature is activated, the clarifier is dis-
abled.
Sending a TELCALL
1. Press the TOGGLE switch (assigned to the “SELCALL” fea-
ture) momentarily to enable selection of the code memory.
2. Rotate the SEL knob to select (display) the code memory of
the station you want to SELCALL.
3. Press the TOGGLE switch (assigned to the “TELCALL” fea-
ture) momentarily to enable to TELCALL feature.
4. Rotate the SEL knob to select the Autopatch memory string
you wish to send.
5. Press and hold in the TOGGLE switch (assigned to the
“TELCALL” feature) for 1/2 second to send the TELCALL
(corresponding to a telephone number).
6. When the communication is finished, press and hold in the
TOGGLE switch (assigned to the “TELCALL” feature) for
1/2 second, while holding in the PTT switch to send the
“Hang-up” signal.
Manual Sending
If your VX-1210 has not had the telephone number stored into
the Autopatch memory, you can pre-program and send the tele-
phone number temporarily.
Here is the manual sending procedure:
1. Call the station that is connected to the telephone system via
the SELCALL feature first, as described previously.
2. Press the TOGGLE switch (assigned to the “TELCALL” fea-
ture) momentarily.
3. Rotate the SEL knob to select (display) “AUX xxxx.”
4. Press and hold in the SEL knob for 1/2 second, then rotate
the SEL knob to select the first digit of the telephone number
you want to send.
5. Press the SEL knob momentarily to step to the next digit’s
place. Use the SEL knob again to select a number and to step
to the next entry.
6. After entering all digits of the telephone number you want to
send, press and hold in the SEL knob for 1/2 second to save
the telephone number into the Autopatch memory temporarily.
7. Press and hold in the TOGGLE switch (assigned to the
“TELCALL” feature) for 1/2 second to send a TELCALL
(corresponding to the telephone number).
SELCALL Operation
The VX-1210 SELCALL feature allow paging and selective call-
ing using 4-digit codes transmitted as an FSK format. Your re-
ceiver remains silent until it receives 4-digit codes that match
those stored in a dedicated code memory.
When the SELCALL feature is activated, the clarifier is disabled.
Receiving a SELCALL
When a SELCALL is decoded, an alert ringer sounds for 30 sec-
onds, and appear the ID code of the calling stations (such as
“ID1234”) will appear in the display. If a private SELCALL is
detected, the VX-1210 send the answer back signal to the call-
ing station automatically before the alert ringer sounds.
Unless you respond, the alert beeper will be heard every three
seconds, and the “
[
CALL RECEIVED
]
plus the
[
calling station’s
ID Code
]
” will appear in the display until you do respond.
Sending a SELCALL
1. Press the TOGGLE switch (assigned to the “SELCALL”
feature) momentarily to enable selection of the code memory.
2. Rotate the SEL knob to select (display) the code memory of
the station you want to SELCALL.
3. Press and hold in the TOGGLE switch (assigned to the
“SELCALL” feature) for 1/2 second to send the SELCALL.
Manual Sending
If your VX-1210 has not been programmed with the 4-digit codes
for the “SELCALL” feature into the code memory, you can pre-
program and send the 4-digit code manually as a temporary mea-
sure.
Here is the SELCALL manual sending procedure:
1. Press the TOGGLE switch (assigned to the “SELCALL”
feature) momentarily.
2. Rotate the SEL knob to select (display) “AUX xxxx.”
3. Press and hold in the SEL knob for 1/2 second, then rotate
the SEL knob to select the first number of the 4-digit code
you want to send.
4. Press the SEL knob momentarily to step to the next digit’s
place. Use the SEL knob again to select a number and to step
to the next entry.
5. After entering all four numbers you want to send, press and
hold in the SEL knob for 1/2 second to save the 4 digits into
the code memory temporarily.
6. Press and hold in the TOGGLE switch (assigned to the
“SELCALL” feature) for 1/2 second to send the SELCALL.
Operating Manual Reprint
ADVANCED OPERATION
