118 VX-1700 Series (EXP Version) Service Manual
PANEL Unit
Parts List
R 3038 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e1
R 3041 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- B c1
R 3043 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B c1
R 3044 CHIP RES. 470 1/10W 5% RMC1/10T 471J J24205471 1- B c2
R 3046 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 3047 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 3048 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 3049 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 3997 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-3
R 3998 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-3
R 3999 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-3
RL3001 RELAY DC12V AGQ200A12Z DC12V M1190188 1- B g1
S 3003 TACT SWITCH SKRPABE010 N5090133 1- A G1
S 3004 TACT SWITCH SKRPABE010 N5090133 1- A H1
S 3005 TACT SWITCH SKRPABE010 N5090133 1- A I1
S 3007 TACT SWITCH SKRPABE010 N5090133 1- A G1
S 3008 TACT SWITCH SKRPABE010 N5090133 1- A H1
S 3009 TACT SWITCH SKRPABE010 N5090133 1- A I1
S 3010 TACT SWITCH SKHHDU N5090080 1- A D3
S 3011 TACT SWITCH SKRPABE010 N5090133 1- A G2
S 3012 TACT SWITCH SKRPABE010 N5090133 1- A H2
S 3013 TACT SWITCH SKRPABE010 N5090133 1- A I2
S 3014 TACT SWITCH SKHHDU N5090080 1- A E3
S 3015 TACT SWITCH SKRPABE010 N5090133 1- A G3
S 3016 TACT SWITCH SKRPABE010 N5090133 1- A H3
S 3017 TACT SWITCH SKRPABE010 N5090133 1- A I3
S 3018 TACT SWITCH SKHHDU N5090080 1- A H4
S 3019 TACT SWITCH SKHHDU N5090080 1- A H3
S 3020 TACT SWITCH SKHHDU N5090080 1- A I4
S 3021 TACT SWITCH SKHHDU N5090080 1- A I3
S 3022 TACT SWITCH SKHHDU N5090080 1- A A4
DIFFUSER SHEET (LCD) RA0727100 1-
REFLECTOR SHEET (BLIND) RA0727200 1-
LIGHT GUIDE (LCD) RA0695900 1-
LCD HOLDER RA0696000 1-
REFLECTOR SHEET RA0696100 1-2
REFLECTOR SHEET RA069610A 3-
INTER CONNECTOR RA0695800 1-
SPONGE RUBBER (LCD) RA0696200 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
