Vertex Standard VX-1700 Series User Manual

3
Exploded View & Miscellaneous Parts
VX-1700 Series (EXP Version) Service Manual
RA0725400
FRONT PANEL ASSY
RA0695500
PACKING PAD (CHASSIS)
RA0694800
KNOB (L)
RA0694900
KNOB (S)
RA069430A
RUBBER KNOB (4KEY)
RA069420A
RUBBER KNOB (12KEY)
RA069440A
RUBBER KNOB (UP/DOWN)
RA069450A
RUBBER KNOB (PW)
CS2286101
MIC UNIT
RA0694600
PACKING PAD (SP)
M4090146
SPEAKER
RA0695000
FRONT PLATE (A)
RA0695000
FRONT PLATE (B)
CS2371101
ENC UNIT
RA0696200
SPONGE RUBBER (LCD)
RA0696000
LCD HOLDER
G6090162
LCD
RA0727100
DIFFUSER SHEET (LCD)
RA0695800
INTER CONNECTOR (2pcs)
RA072720A
DIFFUSER SHEET (BLIND) (x2pcs)
RA0695900
LIGHT GUIDE (LCD)
RA069610B
REFLECTOR SHEET
CB2833001
PANEL UNIT
RA063540A
CHASSIS
CS2213101
PA-4 UNIT
RA0695700
HOLDER PLATE (D-SUB)
RA0695600
HOLDER PLATE (CW)
CB3183001
GPS INTERFACE UNIT
CS1853701
MAIN UNIT
M2090040
FAN
RA0695300
COVER (BOTTOM)
R3100700A
FOOT
R3100700A
FOOT
R0145630
STAND
S4000054
CASE LEG (FF-003)
S4000054
CASE LEG (FF-003)
RA0695200
COVER (TOP)
P1091172A
CONNECTOR
14
13
12
11
10
9
8
7
4
2
14
14
14
14
14
14
14
13
1
13
13
13
6
6
6
6
15
5
3
5
9
2
13
14
14
14
14
7
12
4
4
4
11
12
12
9
9
Non-designated parts are available only as part of a designated assembly.
VXSTD P/N
A06870001
T9023725
Q0000074
RA0696400
DESCRIPTION
MH-31A8J Hand Microphone
DC Power Cord
Spare Fuse (25 A Blade Type)
Switch Label Sheet
QTY.
1
1
1
1
SUPPLIED ACCESSORIES
T9207202A
WIRE ASSY
VXSTD P/N
T9315504
T9315905
T9207120A
T9207210
T9207211
T9207209
T9207117A
DESCRIPTION
Coaxial Cable
(
J1001 J2006
)
Coaxial Cable
(
J1002 J2001
)
30-pin Flat Cable
(
J1003 J2002
)
13-pin Molex
(
J1008 J4001
)
8-pin Molex
(
J1005 J6002
)
8-pin Molex
(
J3004 J6101
)
30-pin Flat Cable
(
J1004 J3001
)
CONNECTION CABLES
REF.
P0001
P0002
P0004
P0005
P0006
P0007
P0008
13
2
2
2
1
1
1
Important Note
The chassis for the PA-4 Unit is different from that of
the PA Unit, because the position of the mounting
screws in PA-4 Unit is different from the PA Unit.
Similarly, the antenna connector for the PA-4 Unit is
different from that of the PA Unit.
Therefore, when replacing the PA Unit to the PA-4
Unit, please replace chassis and antenna connector
at the same time.
VXSTD P/N
U02308002
U03308002
U04410002
U10306001
U20205002
U20306002
U20406007
U20430002
U24106002
U24108002
U24206001
U24208002
U24308002
U31306007
U70004012
SEMS SCREW
SEMS SCREW
SEMS SCREW
TRUSS HEAD SCREW
BINDING HEAD SCREW
BINDING HEAD SCREW
BINDING HEAD SCREW
BINDING HEAD SCREW
TAPTITE SCREW
TAPTITE SCREW
TAPTITE SCREW
TAPTITE SCREW
TAPTITE SCREW
OVAL HEAD SCREW
PLAIN WASHER
SM3X8NI
ASM3X8NI
HSM4X10NI
M3X6
M2.6X5NI
M3X6NI
M4X6B
M4X30(Ni)
M2X6NI
M2X8NI
M2.6X6
M2.6X8NI
M3X8NI
M3X6B
FW4BSNI
QTY.
4
5 (or 7)
1
4
2
4
2
4
6
3
2
4
14
12
1
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
DESCRIPTION
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
RA0635400
CHASSIS
CS1842001
PA UNIT
P1091335
CONNECTOR (FM-MDR-MI)
13
1
13
13
13
2
6
6
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
RA0809600
SPONGE RUBBER
13
RA0809700
PLATE
RA080950A
GUARD PLATE
RA1153600
GROUND PLATE (x2pcs)
RA0693200
SHEET (ALARM)
