126 VX-1700 Series (EXP Version) Service Manual
ENC Unit
Circuit Diagram
Parts Layout
Parts List
Side B
Side A
PCB with Components CS2371101
C 6101 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B
J 6101 CONNECTOR 52746-0890 P1091163 1- B
S 6101 ROTARY ENCODER EC11B15204AU Q9000837 1- A
VR6101 POT. RH96N74 23F B103 RY-7862 J60800285 1- A
VR6102 POT. RH96N220 23F B103 RY-7861 J60800284 1- A
