VX-261 Operating Manual
9
MIC/SP
Jack
(
ExternalMIC/SP
)
controls & connectors
LEDIndicator
(
Programmable
)
 Defaultsettingsare:
 SteadyRed: Transmittinginprogress
 BlinkingGreen:BusyChannel
 SteadyGreen: ToneSquelchindefeatedcondition
PTT
Switch
SIDE-1
Button
SIDE-2
Button
SpeakerMicrophone
BatteryPackLatch
AntennaJack
CH

(
Channel
)
Selector
VOL

(
Volume
)
/PWR

(
Power
)
Knob
