Vertex VX-920 Series - Page 39

39
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
R 1278 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B e1
R 1279 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B d2
R 1280 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d4
R 1281 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A2
R 1281 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 32- A A2
R 1282 CHIP RES. 27 0 1/10W 5% RMC1/10T 271J J24205271 1- A A2
R 1283 CHIP RES. 39 0 1/16W 5% RMC1/16S 391JTH J24189020 1- A A2
R 1283 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 32- A A2
R 1284 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1-3 B a3
R 1285 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d1
R 1286 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
R 1287 CHIP RES. 15 0 1/16W 5% RMC1/16S 151JTH J24189015 1- B d1
R 1288 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 1- B a2
R 1289 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A E1
R 1290 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 1291 CHIP RES. 27 0 1/16W 5% RMC1/16S 271JTH J24189018 1- B d1
R 1292 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- B d1
R 1293 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A E1
R 1294 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E2
R 1295 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049
1- A E1
R 1296 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1297 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A G2
R 1298 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c2
R 1299 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A F3
R 1300 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E2
R 1301 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A E2
R 1302 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d3
R 1302 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 35- B d3
R 1303 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A E2
R 1304 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A E2
R 1305 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A G2
R 1307 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- B c2
R 1308 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E2
R 1309 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d3
R 1309 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 35- B d3
R 1310 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A G3
R 1311 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d3
R 1312 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A F3
R 1313 CHIP RES. 15 0 1/16W 5% RMC1/16S 151JTH J24189015 1- B d3
R 1314 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c3
R 1315 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A G3
R 1317 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F2
R 1318 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c3
R 1319 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- B c2
R 1320 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c2
R 1321 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 1322 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 1323 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d3
R 1324 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c4
R 1325 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- B c3
R 1326 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d2
R 1327 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- B c2
R 1327 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 4- B c2
R 1328 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 1- B d1
R 1329 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c4
R 1330 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c3
R 1331 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
R 1332 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
R 1333 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
R 1334 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
R 1335 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
