Vertex VX-920 Series - Page 42

42
VX-920/-920E VHF series Service Manual
Main Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Parts List
R 1456 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F1
R 1457 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A G1
R 1458 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A G1
R 1459 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A G1
R 1460 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A G1
R 1461 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E1
R 1462 CHIP RES. 18 1/16W 5% RMC1/16S 180JTH J24189004 1- B g2
R 1463 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a3
R 1464 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B3
R 1465 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B3
R 1466 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a1
R 1467 CHIP RES. 68 k 1/16W 5% RMC1/16S 683JTH J24189047 1- B a1
R 1468 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G3
R 1469 CHIP RES. 18 1/16W 5% RMC1/16S 180JTH J24189004 1- B d3
R 1470 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B e3
R 1471 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B d3
R 1472 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 4- B b1
R 1475 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 1476 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 1477 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A H2
R 1478 CHIP RES. 0 1/16W
5% RMC1/16S JPTH J24189070 1- A H2
R 1479 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A C1
R 1480 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- A C1
R 1481 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 1482 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B3
R 1485 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B3
R 1486 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C1
R 1487 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B g2
R 1488 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B g2
R 1489 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 1490 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c2
R 1490 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 4- B c2
R 1491 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 4- A F1
R 1496 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 4- B c2
S 1001 TACT SWITCH SKRTLAE010 N5090130 1- A A3
S 1002 TACT SWITCH SKRTLAE010 N5090130 1- B h4
S 1003 TACT SWITCH SKRTLAE010 N5090130 1- B g4
S 1004 TACT SWITCH SKRTLAE010 N5090130 1- B e4
S 1005 TACT SWITCH SKRTLAE010 N5090130 1- B d4
S 1006 ROTARY SWITCH EC10SP16-93A0 Q9000820 1- B h2
S 1007 TOGGLE SWITCH ATE1E-5M3-17-Z N2090074 1- A A2
T 1001 BALUN TRANSFOMERS #458DB-1676=P3 L0190256 1- B g1
T 1002 BALUN TRANSFOMERS #458DB-1676=P3 L0190256 1- B g2
T 1003 BALUN TRANSFOMERS #458PT-1680=P3 L0190258 1- B f1
TH1001 THERMISTOR TH05 4B473FR G9090150 1- A F2
VR1001 POT. TP76N1034N A203 RY-7671 J60800281 1- B h1
X 1001 XTAL NX1255GC 4.194304MHz 4.194304MHz H0103309 1- A H3
X 1002 XTAL U2G 7.3728MHz 7.3728MHZ H0103281 1- A F3
X 1002 XTAL NX8045GB 7.3728MHz 7.3728MHZ H0103394 64- A F3
X 1003 TCXO 16.8MHz TTS05VS-M1 16.8MHZ H9500830 1- B c3
XF1001 XTAL FILTER MFT50.85P 50.85MHZ H1102361 1- B e1
XF1001 XTAL FILTER MFT50.85P 50.85MHZ H1102361 64- B e1
SHIELD CASE VCO RA0697500 1-
SHIELD CASE VCO RA069750A 4-
SHIELD CASE COVER (MIX) RA0697600 1-
PAD (E1) RA0731500 1-
PAD (E2) RA0731600 1-
ELEC. COND TAPE (MAIN) RA0764600 W/ CE LABEL 7-
ELEC. COND TAPE (MAIN) RA0793400 W/ CE LABEL 7-
SHIELD CASE COVER (FET) RA0760700 W/ CE LABEL 7-
