Using the keypad or arrows, choose the item within the site that needs to be edited, Battery, String etc.
Press F1/Change. Type the new data and press Save/Accept/F2.
To edit another item, repeat the process. When editing is done, you may select the site by pressing
Back/F4 then Select/F1.
Note: Editing is not dependent on whether a .CDF data file is or is not associated with the site to be
edited.
To Set Up a Site Before Test
For best results set up a site before reading voltage or resistance, a site setup is not required for testing,
but is useful for managing many sites. If a site is selected before/after testing, both the readings and site
setup will be saved in the .CDF file.
Figure 57 - CRT Main Menu on LCD/Load Data
Note: The USB flash hard drive must be inserted to accomplish this Load Data function.
Press the right and left arrows to step to a site, then press Select/F1.
