APM 400/600 Optional Components
Yellow LED. On =
The LBS adapter is connected to a non
-
APM
UPS; Off =
Th
e LBS adapter is
connected to an APM UPS
SWITCH
The switch should be placed to right if the LBS adapter is connect
ed to an
APM
UPS
and
to left if the
LBS adapter is connected to a non-APM UPS
Parameter
Specification
Voltage
120
Vac
~
277
Vac
Frequency
45
Hz
~
65
Hz
Current
1.5
A max.
Electrical Parameters
See Table 9.3 below for the LBS adapter electrical parameters
Installation
Note
Before discussing the installation process, remember that only qualified and trained personnel are allowed to install
the LBS adapter due to the hazardous voltage that may exist at the UPS output terminals.
Mounting the LBS adapter
The dimensions of the LBS adapter are indicated in Figure 9-6.
Figure 9-6 LBS adapter dimensions
The LBS adapter may be installed horizontally or vertically, as indicated in Figure 9-7.
Horizontal installation
Vertical Installation
Figure 9-7 Horizontal and Vertical installation
