2.3 Air-flow Configurations
Figure 2.1 Perimeter-unit Air-flow Configuration
Item Description
1 Return air from data center
2 Supplyair to data center
Document Number Title
DPN004718 Airflow Schematic, Perimeter Unit
Table 2.4 Perimeter unit air-flow schematic and duct connection
2 Nomenclature and Components 11
