2 NOMENCLATURE AND COMPONENTS
This section describes the model-number configuration for Liebert® DSE500 units and components.
2.1 Liebert DSE500 Packaged Solution Model-number Nomenclature
Table 2.2 below describes each digit of the model number.
Model Number Digits 1 to 10 Model Details
Model Number
Digits 11 to 14
1 2 3 4 5 6 7 8 9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
1
2
2
2
3
2
4
2
5
D P 5 0 0 T P 2 A T 0 H 0 8 1 6 L 0 U 0 P — — — 1
Table 2.1 DSE500 Model Number
Digit Description
Digits 1 and 2 = Product Family
DP = Liebert® Packaged DSE
Digit 3to5 = Cooling Capacity, kW
Nominal sensible capacity, kW
Digit 6 = Air Discharge
F = Perimeter, front inlet/front supply
R = Roof-top, bottom supply/bottom return
Digit 7 = System Type
P = Air-cooled, Econ-O-Phase ready
Digit 8 = Air-flow (Fan Type)
2 = Direct-drive plenum, TEFC + VFD
Digit 9 = Power Supply
A = 460V - 3ph - 60Hz
Digit 10 = Cooling System
T = Tandem with digital scroll, R-410A
Digit 11 = Humidifier
0 = None
Digit 12 = Display
H = Liebert® iCOM control
Digit 13 = Options
0 = None
A = Air isolating dampers:
Digit 6 = F - Dampers on front supplyand return
Digit 6 = T - Dampers on front supply only
Digit 14 = Air Filter
8 = MERV 8, 4-in.
Table 2.2 DSE500 Packaged Solution Model-number Digit Definitions
2 Nomenclature and Components 9
