Figure 5.3 Low-voltage iCOM/vNSA switch wiring to unit in Main electrical enclosure
Item Description
1 Location of the connection for CAT5 cable from Liebert® VNSAICOM8 network switch.
Figure 5.4 120-V UPS power-feed connection for low-voltage controls in Main electrical enclosure
