Vertiv I Liebert Air Cooled Condenser I User Manual 2
1.3 Main Components
The main components of the condenser include the heat exchanger, fan, fan speed controller
and pressure sensor. The heat exchanger is inside the condenser, and the appearance and
position of other components are shown in Figure 1-2 and Figure 1-3.
Figure 1-2 Condenser (single fan, single circuit)
Isolation switch
Electrical control box (with a fan speed
controller inside)
Pressure sensors
Figure 1-3 Condenser (double fans, dual circuit)
Electrical control box (with a fan speed
controller inside)
Isolation switch
Pressure sensors
