Vertiv Liebert Mini-Mate MT048 - CABINET DIMENSIONAL DATA 3 ΤΟΝ DIRECT EXPANSION FAN;COIL MODULE

REV : 0
REV DATE : 06/18
DPN004800
Page :1 /1
Form No.: DPN001040_REV4
3 TON DIRECT EXPANSION FAN/COIL MODULE
CABINET DIMENSIONAL DATA
LIEBERT MINI-MATE
VARIABLE CAPACITY
Front of Unit
Discharge Side
of Unit
Rear of Unit
Return Air Side
of Unit
Electrical
Access Panel
UNIT NET WEIGHT
lbs. (kg)
328 (149)
MT036HE1
MODEL
NUMBER
Bottom Return
Bottom Discharge
Discharge
Side of Unit
Return Air
Side of Unit
13 7/8"
352mm
30"
762mm
Front of Unit
Removable
Access Panel
24"
610mm
54"
1371mm
Removable
Access Panel
17 7/8"
454mm
13 7/8"
352mm
10 7/8"
276mm
Bottom of Unit
7 3/8"
188mm
8 1/2"
216mm
23 1/2"
597mm
7 5/8"
194mm
18 1/2"
470mm
4"
102mm
13 3/4"
349mm
4 1/2"
114mm
27 13/16"
707mm
Rear of Unit
55 13/16"
1417mm
57 13/16"
1468mm
4 5/8"
117mm
17 7/8"
454mm
4 5/8"
117mm
11 3/4"
298mm
31"
785mm
