Vertiv Liebert PSA5 - Front and Rear Panel Controls and Features

1.2 Front and Rear Panel Controls and Features
Figure 1.1 Controls and Indicators
ITEM DESCRIPTION
1 Power button.
2 Silence-alarm button.
3
Scroll button.
To scroll through the LCD-display parameters.
4 LCD display
5 USB charging ports, 5V/2.1A max. combined
6 Surge-protected only receptacles.
7 Battery-backed and surge-protected receptacles.
8 USB communication port (Type B)
9 RJ11/45 connectors for phone/fax/modem or network surge protection.
10 Coax connectors for cable-TV or cable-modem or DSS-receiver surge protection.
11 Input Circuit Breaker
12 Input power cord (NEMA 5-15P)
Vertiv | Liebert® PSA5™ Installer/User Guide | 8
