PARALLEL OPERATION Liebert Trinergy™ Cube
User Manual - 10H52243UM60 - rev. 6 - 12/2020 Page 21
5.7. Procedure 4: TRANSFER FROM MAINTENANCE BYPASS MODE TO NORMAL MODE
Starting with each UPS in maintenance bypass, this procedure explains how to turn ON the UPS and to
transfer the load to normal mode. Then, after a short period, it selects the appropriate operating mode,
which depends on the ambient conditions it has detected. Perform the following procedure on each UPS:
STEP ACTION STATUS
1
Energize all the UPS in the system by closing the upstream
breakers (mains and bypass)
Once the all the UPS have been energized apply the following steps to all UPS in the system
2 Switch QS1 on Box to ON position (all UPS)
Only in case of BOX in
version FULL
3 Switch QS1-n on each Core to ON position (all UPS)
4 Wait for Rectifier on each Core ON position
On the TS-LCD the Rectifier
icon is green and the VDC is
> 700V
5 Switch QS44 to ON position (all UPS)
6 Switch QS2 to ON position (all UPS) Fans on the BOX ON
7 Switch QS4_n on each Core to ON position (all UPS) Fans on each Core ON
8
Switch QS9_n on each Core to ON and Close the external
battery disconnector (all UPS)
9 Switch QS4 on Box to ON position (all UPS)
Only in case of BOX in
version FULL
10
Open the external maintenance bypass switch
In case the system is put in maintenance bypass with the
Internal switch, open QS3 in all Box
Only in case of BOX in
version FULL
Once the previous steps have been performed for all UPS in the system proceed with the further
steps
11
Turn inverter ON by pressing the ON button
on the TS-LCD of each UPS
System in normal mode
To Next Page
