Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
16
Figure 5: Installing an Optional Bullet Nose Type 6-Position GMT Distribution Fuse Block (P/N 550224)
Press in tabs to release
lug terminal busbars for
positions to be occupied
by GMT Fuse Block.
Remove two lug terminal busbars
for positions to be occupied
by GMT Fuse Block.
Plug in GM T Fuse Block and secure
at two locations on the RTN bar.
Torque to 72 in-lbs.
RTN Bar
GMT Fuse Block Installed View
1.
2.
3.
