Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
17
Figure 6: Installing an Optional Bullet Nose Type 6-Position GMT Distribution Fuse Block (P/N 549017)
RTN Bar
1. Remove two lug terminal busbars for positions to be occupied
by GMT Fuse Block. Remove plastic busbar plugs first.
Plastic Busbar Plugs
2. Plug in GMT Fuse Block.
3. Connect supplied jumper from
GMT Fuse Block to Return Bar.
Torque to 75 in-lbs.
Part of P/N 549017
Part of P/N 549017
