Direct AC Input Connections to the Module Mounting Assemblies
• The system can be equipped with module mounting assemblies that contain AC input terminal blocks
which provide a separate single phase AC input connection for each rectifier position (588705000 List
31; 588705500 List 03).
• The system can be equipped with module mounting assemblies that contain AC input terminal blocks
which provide a separate three phase AC input connection for every three (3) rectifier positions
(588705000 List 32 and List 33; 588705500 List 04 and List 05).
• The system can be equipped with module mounting assemblies that contain AC input line cords (one
for each rectifier module position) (588705000 List 22; 588705500 List 02).
• The system can be equipped with module mounting assemblies that contain AC input cable assemblies
or AC input line cords which provide a separate single phase AC input connection for every two (2)
rectifier positions (588705300 List 03).
• The system can be equipped with module mounting assemblies that contain AC input cable assemblies
or AC input line cords (one for each rectifier module position) (588705400 List 02).
• The system can be equipped with module mounting assemblies that contain AC input line cords which
provide a separate three phase AC input connection for every three (3) rectifier positions (588705400
List 03 and List 04).
Connections to AC Input Termination Assemblies (582127000 List 40, 41, 42, 43) (For System Mounted
in a Relay Rack)
Refer to Figure 9, Figure 10, Figure 11, or Figure 12 as these procedures are performed.
NOTE! Terminal blocks for a system with maximum possible rectifier shelves shown. Your system may
have less terminal blocks then shown.
