Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
44
Figure 19: Nominal 277 VAC / 480 VAC Input Connections (Three-Phase) to a 588705000 List 33 and
588705500 List 05 Module Mounting Assembly
Holes for 3/4"
Conduit Fitting
(AC Input)
Holes for 3/4"
Conduit Fitting
(AC Input)
Rear View
Rear View
FRAME GROUND CONNECTION
ONE 10-32 X 3/4" STUD
AND HARDWARE.
Recommended torque: 23 in-lbs.
FRAME GROUND CONNECTION
ONE 10-32 X 3/4" STUD
AND HARDWARE.
Recommended torque: 23 in-lbs.
Rectifier Module (PCU) Mounting Slots
(front view)
Rect.
(PCU)
1
Rect.
(PCU)
2
Rect.
(PCU)
3
Rect.
(PCU)
4
Rect.
(PCU)
5
Rect.
(PCU)
6
AC IN
Feed 2
(Rectifier
Modules
4-6)
AC IN
Feed 1
(Rectifier
Modules
1-3)
RECTIFIER (PCU) AC INPUT FEEDS
1 FEED PER 3 RECTIFIERS (PCU)
277 VAC / 480 VAC, 50 Hz / 60 Hz, THREE PHASE
Wire Size Capacity: 8-24 AWG.
Recommended Torque: 18 in-lbs.
Wire Size Capacity: 8-24 AWG.
Recommended Torque: 18 in-lbs.
CONNECTIONS WITHIN THE SHELF
TB1, Terminal
Mounting
Position
L1 L2 L3
L1
L2
L3
Rect 6
Rect 5
Rect 4
Rect 3
Rect 2
Rect 1
N
N
N
N
TB2, Terminal
L1 L2 L3
L1
L2
L3
N
N
N
N
