Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
63
Table 2: Programmable Relay Outputs – IB2 Board
Programmable
Relay Output
IB2
Pin No.
Alarms Assigned to this
Relay (Default)
Alarms Assigned to this
Relay (Custom)
1
NO J6-5
The relays may be
preprogrammed for specific
functions. Refer to the
configuration drawing (C-
drawing) supplied with your
system for your system’s
specific configuration.
COM J6-3
NC J6-1
2
NO J6-6
COM J6-4
NC J6-2
3
NO J7-5
COM J7-3
NC J7-1
4
NO J7-6
COM J7-4
NC J7-2
5
NO J8-5
COM J8-3
NC J8-1
6
NO J8-6
COM
J8-4
NC J8-2
7
NO J9-5
COM J9-3
NC J9-1
8
NO J9-6
COM J9-4
NC J9-2
NOTE! The relay assigned to “Critical Summary” alarm (relay 1 by default) will operate in the “Fail Safe
Mode”. “Fail Safe Mode” means Relay 1 is de-energized during an alarm condition, opening the contacts
between the C and NO terminals, and closing the contacts between the C and NC terminals.
The remaining 7 relays energize during an alarm condition, closing the contacts between the C and NO
terminals, and opening the contacts between the C and NC terminals.
Refer to the configuration drawing (C-drawing) supplied with your system for your system’s specific
relay labeling.
