Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
94
Figure 57: List DE: -48 VDC / +24 VDC Distribution Panel, (22) -48 VDC Bullet/TPS/TLS Circuit Breaker/Fuse
Positions (with Return Busbar) and (4) +24 VDC Bullet/TPS/TLS Circuit Breaker/Fuse Positions
(with Return Busbar)
Figure 58: List DF: -48 VDC / +24 VDC Distribution Panel, (18) -48 VDC Bullet/TPS/TLS Circuit Breaker/Fuse
Positions (with Return Busbar) and (8) +24 VDC Bullet/TPS/TLS Circuit Breaker/Fuse Positions
(with Return Busbar)
O
bserve proper
polarity when making
load connections.
WARNING!
-
4
8V
D
i
s
tr
i
bu
t
i
on
+24
V
D
i
s
tr
i
b
u
ti
o
n
LOAD AND LOAD RETURN CONNECTIONS
1/4-20 Studs on 5/8” Centers
(Customer must supply
or order additional
hardware)
Maximum Lug Width:
0.625 inches.
Load
Connections
Load Return
Connections
Caution: 100 A circuit breakers and fuses can be used without a space
provided the continuous operating current in each 100 A device does not exceed 64 A.
A 175 A or greater circuit breaker shall have an empty mounting position between it
and any other overcurrent protective device.
O
bserve proper
polarity when making
load connections.
WARNING!
-
48
V
D
i
s
tr
i
bu
t
i
o
n
+
2
4
V
D
i
s
tr
i
b
uti
on
LOAD AND LOAD RETURN CONNECTIONS
1/4-20 Studs on 5/8” Centers
(Customer must supply
or order additional
hardware)
Maximum Lug Width:
0.625 inches.
Load
Connections
Load Return
Connections
Caution: 100 A circuit breakers and fuses can be used without a space provided
the continuous operating current in each 100 A device does not exceed 64 A.
A 175 A or greater circuit breaker shall have an empty mounting position between it
and any other overcurrent protective device.
