Vertiv | NetSure Rectifier Module User Manual (UM1R483000e3) | Rev. 1.0
14
Table 5: Exchange of Information between Rectifier and Controller
COMMANDS / SIGNALS THAT CAN BE RECEIVED
BY THE RECTIFIER MODULE FROM THE
CONTROLLER.
INFORMATION GATHERED BY THE CONTROLLER
FROM THE RECTIFIER MODULE.
Turn On/Off
Current Walk-in On/Off
HVSD (High Voltage Shutdown) Reset
Current Limit Adjustment
Voltage Regulation
Input Voltage
Output Voltage
Output Current
Current Limit Setting
Temperature
Over Voltage Setting
On/Off Status
Fault Alarms, such as:
HVSD
Fan Fail
Protection Alarms, such as:
Input Voltage Protection
Inner DC Bus Voltage Protection
High Temperature Protection
Thermal Derating
AC Derating
AC Fail
Imbalance Output Current
Address
Code
Date
Software Version
Hardware Version
Mechanical Specifications
• Dimensions:
a) Millimeters: 42.0 (Height) X 84.5 (Width) X 330 (Depth)
b) Inches: 1.7 (Height) X 3.3 (Width) X 13.0 (Depth)
• Weight: 3 kg (6.6 lbs)
• Indicators:
a) Power (Green LED)
b) Protection (Yellow LED)
c) Alarm (Red LED)
