Vertiv I VRC Self-Contained System I User Manual
2.4 Unpacking
Unpacking the unit is show in Figure 2-5 below.
Figure 2-5 Unpacking
NOTES:
• Packing materials of the unit are recyclable. Retain the packing materials for further use or dispose
them appropriately as per the protocols and local regulations.
Wooden case
EPE
Wooden pallet
EPE
Ceiling tile kit
(4)
Cooling unit
(19)
Transition Part (1)
Duct (2)
Pump Bracket (Pump is
preinstalled) (5)
EPE
SIC Card (8)
L-shape Mounting Rail
(7)
