Vertiv VRC100 - Maintenance Guidance for Fan Kit

47
Vertiv I VRC Self-Contained System I User Manual
Figure 7-7 Sheet metals of the ceiling tile for filter pad
7.11 Maintenance Guidance for Fan Kit
• Periodic inspection covers the state of the fan impellers, fastening of fan components, abnormal fan
noise, and fan cable connection.
• Pay close attention to assess whether the fan kit and impeller are properly fixed, and the rotation of
Through hole
for M5 screw
Two limit
columns
M5 screw
threaded hole
Two limit
holes
Front
Rear
