5 Controller Operation Instructions
This chapter gives a detailed description of the features, appearance, LCD screen, control buttons, control
interface and menu structure of the air conditioner.
5.1 LCD Screen
The backlit LCD screen displays English menus. Figure 5-1 depicts the image of the controller display.
Figure 5-1 Controller display
5.2 Control Buttons
The micro-processing controller provides five control buttons, as shown in Figure 5-2, below.
Figure 5-2 Control buttons
To Next Page
