Vertiv I VRC Self-Contained System I User Manual
System Parameters Normal Range
Item
Range
Suction Pressure (Gauge)
800 kPa (116.0 psig) – 1500 kPa (217.6 psig)
Discharge Pressure (Gauge)
2000 kPa (290.1 psig) – 3600 kPa (522.1 psig)
Discharge Temperature
40
o
C (104
o
F) – 115
o
C (239
o
F)
Tret - Tsup
3
o
C(37
o
F) - 50
o
C (122
o
F)
• If any abnormal operation is noticed, stop the unit by pressing the ‘ON/OFF’ button on the display
board for 3 seconds, and disconnect all air circuit breakers.
6.4 Commissioning Complete Inspection
Inspect the items in Table 6-2, Checklist after Commissioning.
Table 6-2 Checklist after commissioning
Inspection Items
Inspection Results
Check that all outputs are functional.
Check that the temperature settings are correct and are controlled within range.
Check that there are no abnormal alarms or warnings displayed on the controller.
Make sure all the other functions are set correctly.
