LaserSCANNER Installation Manual VESDA
®
6 Version 1.3
CE = Cable Entry Port (25.4mm, 1.0in ∅)
CP = Exhaust Pipe Outlet Option or Cable Entry Port
Figure 2 Dimensions in mm (in) for the LaserSCANNER
26.0(1.02)
34
(1.33)
26.0
(1.02)
350(13.8)
35
(1.37)
45.0
(1.77)
34
(1.33)
34
(1.33)
34.0
(1.33)
Inlet Air Ports
CE
TOP VIEW
RIGHT HAND
SIDE VIEW
LEFT HAND
SIDE VIEW
FRONT VIEW
28.5
(1.12)
CP
CE
225
(8.9)
26.0
(1.02)
25.4
(
1.0
)
125 (4.9)
BOTTOM VIEW
141.4 (5.58)
26.0
(1.02)
CE
Exhaust Air
Port
35
(
1.37
)
45.0
(1.77)
20.2
(0.88)
