Turn signal lights
SIGNAL LIGHTS AND HORN
Specification
Desc./Quantity
1 Turn signals master-box
2 Indicators switch
3 Turn signal warning light 12V - 1,2W
4 Turn signal light bulbs 12V - 21W
5 Horn button
6 Horn
7 Voltage regulator
8 Key switch contacts
9 Fuse 7,5A
10 Battery 12V - 9Ah
Electrical system Vespa PX 150 USA
ELE SYS - 40
