Vespa S 125ie 3Valvole User Manual

01_05
Locking the steering wheel (01_05)
Turn the handlebar to the left (as far as it will go), turn the key to «LOCK» and remove
the key.
CAUTION
DO NOT TURN THE KEY TO «LOCK» OR «KEY OFF» WHILE RIDING.
01_06
Releasing the steering wheel (01_06)
Reinsert the key and turn it to «OFF».
CAUTION
DO NOT TURN THE KEY TO «LOCK» OR «KEY OFF» WHILE RIDING.
13
1 Vehicle

Vespa S 125ie 3Valvole Specifications

General

Fuel System	Electronic Fuel Injection
Transmission	Automatic CVT
Front Brake	200 mm disc
Rear Brake	140 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Max Torque	10.2 Nm at 6, 000 rpm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
Rear Suspension	Helical spring with adjustable hydraulic shock absorber
