Vespa S 125ie 3Valvole User Manual

01_23
Bag clip (01_23)
To use the retractable bag hook «B» mounted on the leg shield back plate, pull it
slightly towards the back of the vehicle.
01_24
Helmet Anti-theft Device (01_24)
When lifting the saddle, as described in paragraph «Saddle opening», you can reach
the antitheft device «A» at which it is possible to secure a helmet.
CAUTION
IN ORDER TO AVOID ENDANGERING THE STABILITY WHEN RIDING, DO NOT
RIDE THE SCOOTER WITH THE HELMET INSERTED INTO THE ANTITHEFT DE-
VICE.
CAUTION
THE INDICATED COMPONENT «B» REPRESENTS THE AIR INTAKE OF THE
MOTOR: DO NOT OBSTRUCT EXTERNALLY OR INTERNALLY, WITH ANY OB-
JECT, THE ENDS UNDER THE SADDLE, IN ORDER TO AVOID SERIOUS EN-
DANGERING OF THE VEHICLE.
22
1 Vehicle

Vespa S 125ie 3Valvole Specifications

General

Fuel System	Electronic Fuel Injection
Transmission	Automatic CVT
Front Brake	200 mm disc
Rear Brake	140 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Max Torque	10.2 Nm at 6, 000 rpm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
Rear Suspension	Helical spring with adjustable hydraulic shock absorber
