Vespa S 125ie 3Valvole User Manual

03_17
Battery (03_17)
To access the battery, tilt the saddle forwards, then remove the battery compartment
access door by unscrewing the star-shaped screw "A" shown in the figure.
The battery is the electrical device that requires the most frequent attention and the
most thorough maintenance.
WARNING
USED BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION
AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH REGULA-
TIONS IN FORCE.
CAUTION
ELECTROLYTE CONTAINS SULPHURIC ACID: AVOID CONTACT WITH EYES,
SKIN AND CLOTHES. IN CASE OF ACCIDENTAL CONTACT, RINSE WITH ABUN-
DANT WATER AND CONSULT A DOCTOR.
CAUTION
IN ORDER TO AVOID DAMAGING THE ELECTRIC SYSTEM, NEVER DISCON-
NECT THE WIRING WHILE THE ENGINE IS RUNNING. DO NOT TIP THE VEHICLE
TOO MUCH IN ORDER TO AVOID DANGEROUS LEAKAGE OF THE BATTERY
ELECTROLYTE.
51
3 Maintenance

Vespa S 125ie 3Valvole Specifications

General

Fuel System	Electronic Fuel Injection
Transmission	Automatic CVT
Front Brake	200 mm disc
Rear Brake	140 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Max Torque	10.2 Nm at 6, 000 rpm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
Rear Suspension	Helical spring with adjustable hydraulic shock absorber
