1.4 Engine lifting
WARNING Handle the unpacked unit with care!
When you install the generator set on the boat after opening the packaging
always follow the hoist instructions below.
Preferably use a spacer rod as shown in the drawing lift the engine.
Assure that the spacer rod is in ‘good condition‘ and strong enough to with-
stand the weight.
WARNING
The lifting hooks are engineered only to lift the
generator set without any extra weights!
MIN.
150 cm
(5 ft)
