VEVOR FLO700 - Installation Instructions

- 3 -
S/N
Name
Number
A-B
Check valve with plastic elbow
1
C
Hose Clamp (32-50mm)
4
D
Rubber ring to connected the Intelflo toilet and Intelflo
pump
1
E
Plastic hose
3
F
Activated Carbon
1
G
Hose Clamp (90-110mm)
1
H
Hose Clamp (110-120mm)
1
J
Lid
1
K
Plug(It Mounted On The Pump)
3
INSTALLATION INSTRUCTIONS
(5-1), Install the rubber sleeve (D) onto the sewage pump and lock it with a
90- 110mm hose clamp(G). Be careful not to install the rubber backwards.
(5-2), The customer can select accessory A-B and check that the hose
clamp of the accessory is locked before installation. Then the customer
chooses the size of the drain pipe, which is available in l" (28mm), 1- 1/4"
(32mm), or 40mm (l- l/4") sizes. The dimensions are marked on the
