VEVOR S4040 - B. Mounting base

- 3 -
B. Mounting base
Required
Parts
NO.
Name
QTY
4
Base
1
5
Gantry frame
1
6
M5*20 Screws
8
Step：
As shown in Figure 2, place the gantry on the base and secure it with
M5*20mm screws.
Figure 2
