MODEL:S4040
A. Mounting base
Required
Parts
Name
QTY
Right side of
the Y axis
1
Left side of Y
axis
1
Base structure
2
M5*16 Screws
8
Step：
1. The base structure and left and right Y axis are placed as shown in
Figure 1.
2. Fix it with M5*16 screws (as shown by arrow).
Figure 1
