F. Mounting spindle
Required Parts
Name
QTY
Motor fixture
1
Spindle motor
1
M5*55 Screws
4
Step
：
1. Place the main shaft on the gantry frame as shown in Figure 4.
2. Fix the main shaft to the gantry frame with M5*55 screws.
Figure 4
