6. Assemble the LED lamp (No.3) with lamp clips(No.4) by M4*10 screw(No.5)
and nut(No.6).
7. Put the lamp wires into sealing joint(No.13) and insert it into the left cabinet
plate. Tight the joint. Connect the wire with the switch box (No.10) and fix with
cabinet by M5*10 screw(No.11) and nut(No.12).
8. Fix the viewing window(No.1) with the hinge of cabinet by M4*10 screw(No.7)
and nut(No.8).
9. Fix the gas spring (No.2) to viewing window and cabinet.
10. Stick the sealing foam around the inside of the viewing window.
11. Block the black cover(No.9) on the bottom.
Note：
1.The chamfer side of the mesh should be placed on the air intake side of the
cabinet which is convenient to insert the sand pipe.
2. The sealing joint should be unscrewed, then insert the wires and screw again.
3. The stainless steel parts of air spring should be downwards.
6. PACKING LIST
No.
Name
Q'ty
No.
Name
Q’ty
1
Window plate
1
17
Hex nut M4 of door lock
4
1-1
Plexiglass (with 1 film)
1
18
Glove clamp
2
1-2
Window frame
1
19
Glove (pair)
1
1-3
Cross pan head screw &
nut M5*25
10
20
Working net
1
