MANUAL VIAVAC-CB4 / 4.1 ( Expert section ) Art. nr. 50504 EN (01-07-2017)
__________________________________________________________________________________________
23
___________________________________________________________________________________
VIAVAC vacuum lifting BV T. + 31 348 449 660 E. info@viavac.com I. www.viavac.com
X = Recommended spare part
X = Recommended spare part
CABLE REMOTE CONTROL
Art. no. 278201
A
B
C
D
E
F
G
1
Pict.
Quan.
Description
Type
Art. no.
A
1-A
1
Connector
male
155101
1-B
1
Connector switch NC
ZC2-BE102
9070
X
1-C
1
Connector switch NO
ZB2-BE101
9069
X
1-D
1
Rubber covered magnet
19mm
227102
1-E
1
Green button
XAC-A413
9068
X
1-F
1
Red button
Male
9067
X
1-G
RADIO REMOTE CONTROL
Art. no. 278206
A
B
C
D
E
F
G
1
Pict.
Quan.
Description
Type
Art. no.
A
1-A
1
Remote control transmitter
3 buttons + code
279304
X
1-B
1
Remote control receiver
12-24Vdc 5 functions
152501
