Chapter A Appendix A: RCI commands
OEMDC Measure
22166183 R001 PSD90-3 Universal AC/DC Fuel Quantity Test Set Operation Manual FINAL
March 2023 Subject to Export Control; see Cover Page for details. A - 55
A.7.2 Read Measurement
A.8 OEMDC Measure
The following sections describe the OEMDC Measure commands.
A.8.1 Measurement Range
Co mmand :DCCAP:READ: CAP?
De s cript ion Command r eturns the most recent reading in ρF.
Re spons e Ex a mpl e 25.251
Co mmand :DCCAP:READ: PHASE?
De s cript ion Returns the most recent phase, in degrees.
Re spons e Ex a mpl e 1
Co mmand :OEMDC:RANGE <range>
De s cript ion Sets the current range of t he OEMDC measurement. Also sets
the ranging mode to MANUAL.
Para m ete rs <range>
The new range, in ρF. Mus t be one of the following:
– 400
– 2000
Ex a mple :OEMDC:RANGE 2000
Co mmand :OEMDC:RANGE?
De s cript ion Returns the current range, in ρF.
Ex a mple :OEMDC:RANGE?
Re spons e Ex a mpl e 400
