A.10.1 Measurement Range
Co mmand :MEGGER: RANGE <range>
De s cript ion Command sets the current range of the MEGGER measurement.
Also sets the ranging mode to manual.
Para m ete rs <range> The new range. Must be one of the following:
– 40
– 400
– 4k
– 40k
– 400k
– 4M
– 40M
– 400M
– 4G
– 20G
Re spons e Ex a mpl e 400K
Co mmand :MEGGER: RANGE?
De s cript ion Command r eturns the current range.
Ex a mple :MEGGER: RANGE?
Re spons e Ex a mpl e 400K
Co mmand :MEGGER: AUTO <is_auto>
De s cript ion Command will set the cur rent ranging mode for the MEGGER
measurement.
Para m ete rs <is_auto>
1 for AUTO
0 for Manual.
Ex a mple :MEGGER: AUTO 1
Co mmand :MEGGER: AUTO?
De s cript ion Command r eturns the current ranging mode. 1 for AUTO, 0 for
Manual.
Ex a mple :MEGGER: AUTO?
Re spons e Ex a mpl e 1
