5
2. Specifications
1. Common Specifications
1. Measurement system..................Electromagnetic force balancing system
2. Tare range ...................................Total capacity
3. Liquid-crystal display (LCD).........Indication in max. 8 digits (Weight indications produced
in 7 digits, in characters 18 mm high)
4. Calibration (Span Adjustment).....Span adjustment with built-in weight (Auto-span
adjustment)*
Span adjustment with external weight.
5. Measuring function......................Weight mode, counting mode, percentage mode,
addition mode, and density mode.
6. Various functions .........................ISO/GLP/GMP functions. (Compatible printer:CSP-160)
Calendar and clock function
7. Overload indication......................[
] is displayed if the weighing capacity + 9
graduations are exceeded.
8. Operating temperature and humidity ranges
.....................................................10°C to 30°C, 80%RH or less.
9. AC adapter ..................................Dedicated AC adapter: UM019 (9 VDC, 700 mA/120
VAC), or UM069 (9 VDC, 600 mA/230 VAC)
10. Output..........................................Bidirectional RS232C output
Output for peripherals
* Applies only to models with the built-in weight
2. Specifications by Model
Model AF-R220 AF-220
Capacity 220 g 220 g
Scale interval* 0.0001 g/0.0002 g/0.0005 g/0.001 g/0.002 g
Measurable unit weight 0.0001 g 0.0001 g
%-limit weight value 0.01 g 0.01 g
Size of measurement pan
φ80 mm
Weight of main unit Approx. 5.5 kg Approx. 5 kg
Built-in weight Provided Not provided
* Changeable by switching Function 1
