Vichy VC8145A - Specifications; Reading Rates

SECTION 6
Specifications
INTRODUCTION
This Section contains the specifications of the Dual Display Multimeter. These specifications assume:

A 1-year calibration cycle

An operating temperature of 18℃ to 28℃ (64.4℉~82.4℉)

One-hour warmup

Slow reading rate

Relative humidity not exceeding 70% (non_condensing)
Accuracy is expressed as ± (percentage of reading + digits).
READING RATES
DC VOLTAGE
Input Impedance
1000MΩ at 300mV and 3V. 10MΩ at other ranges.
Normal Mode Rejection Ratio (NMR)
≥60dB (at 50Hz or 60Hz)
Common Mode Rejection Ratio (CMR)
≥120dB (at 50Hz or 60Hz)
Maximum Input
1000V peak
TRUE RMS AC VOLTAGE, AC-COUPLED
Range Resolution Accuracy
20~50Hz 50 Hz~10KHz 10~20KHz 20~30KHz 30~50KHz
300mV 10uV 2%+30 0.5%+30 1%+80 5%+80 10%+150
3V 100uV
30V 1mV 3%+30
300V 10mV
750V 100mV
Rate Readings per Second
Slow（S） 3
Fast（F） 5~7
Range Resolution Accuracy
300mV
3V
30V
300V
1000V
10uV
100uV
1mV
10mV
100mV
0.03%+3
19
