KM 2800-3200-4000-4000S
Operator´s Manual
Translation of the original operator’s manual
Date of publication 06/2011
Date printed 06/2011
Language EN
Valid as from serial No.: KT 418.065
Reference No: 90061200EN
Index 2011-06

Table of Contents

Questions and Answers

  • P
    Patricia BrownAug 19, 2025
    How to fix irregular stubble with Vicon Farm Equipment?
    • N
      nicoleporterSep 12, 2025
      To correct irregular stubble when using Vicon Farm Equipment, several factors should be checked. Ensure that the blades are not dull or bent by reversing or replacing them. Increase the PTO speed to 540 if it's too low, or slow down if the forward speed is too high. Also, verify that the blades are mounted in the correct rotating direction. If long material is wrapping around the drums, check the PTO rpm. Finally, consider fitting the wide inserts.
  • K
    Kenneth ReyesAug 21, 2025
    What to do if Vicon Farm Equipment has excessive vibration or noise?
    • C
      crystal81Aug 21, 2025
      If your Vicon Farm Equipment is experiencing excessive vibration or noise, immediately stop the machine and inspect it to identify the cause before continuing work. Check that the coupling shafts are correctly mounted and that the correct coupling shaft is being used.
  • M
    Michael ReedAug 23, 2025
    Why does my Vicon KM 2800 Farm Equipment mower make too much noise when switched on?
    • R
      Robert ArmstrongAug 23, 2025
      If your Vicon mower is making excessive noise when switched on, the tractor rpm may not match the mower rpm (540 rpm). Check that the tractor p.t.o rpm matches 540 rpm. Also, the RPM may be too high.
  • S
    spencerbellAug 26, 2025
    Why does Vicon KM 2800 machine take too much power?
    • J
      Jodi PrattAug 27, 2025
      If your Vicon Farm Equipment machine is consuming too much power, check the temperature of the boxes and cutter bar, as the oil level may be too high in the cutter bar or gearboxes. Also, check for and remove any rope coiled around the bearing house under the disc, and reduce driving speed if it's too high.
  • L
    Lauren HarrisAug 28, 2025
    How to prevent blade breakage in stony areas with Vicon KM 2800?
    • C
      Cassidy WellsAug 28, 2025
      To reduce regular blade breakage and excessive wear in stony areas when using Vicon Farm Equipment, ensure the cutter bar is as level as possible to prevent stones from being thrown into the machine. Try cutting higher using the accessory skids, and consider mounting the heavy-duty blades.
  • J
    Jorge RoyAug 30, 2025
    Why are there waves in the cutting pattern of my Vicon KM 2800 Farm Equipment?
    • B
      Briana McintyreAug 30, 2025
      Waves in the cutting pattern when using Vicon Farm Equipment can be due to excessive speed. Try slowing down. Additionally, the ground pressure may be too low; readjust it to the appropriate level.
  • J
    justin76Sep 1, 2025
    What causes an irregular swath with Vicon KM 2800?
    • A
      Angela TurnerSep 1, 2025
      An irregular swath with Vicon Farm Equipment can result from crop accumulation on the skid; try lowering the PTO speed. If long material becomes wrapped around the drum, increase your driving speed. Also, consider fitting the wide inserts.
  • I
    Isaac NicholsSep 4, 2025
    Why is the manual disc rotation stiff on my Vicon KM 2800?
    • A
      Alyssa ScottSep 4, 2025
      If the manual disc rotation runs stiffly on your Vicon Farm Equipment, it could be due to several reasons. The disc guard might be bent upward too steeply, causing the disc to jam; return the disc guard to its correct position. Also, check for and remove any dirt or rope under the discs. Finally, ensure the knife bolt is mounted correctly.
  • P
    Patricia PerezSep 6, 2025
    Why do the blades touch the discs on my Vicon Farm Equipment?
    • D
      Dakota ArmstrongSep 6, 2025
      If the blades are touching the discs on your Vicon Farm Equipment, it may be due to incorrect blade length. Ensure you mount blades of the correct length. Alternatively, the disc timing may be off, so time the discs accordingly.
  • J
    Jessica LewisSep 9, 2025
    Why mowing unit wil not lift in a horizontal way on Vicon Farm Equipment?
    • M
      Maria BakerSep 9, 2025
      If the mowing unit will not lift horizontally on your Vicon Farm Equipment, the ground pressure setting may be unequal on either side. Adjust the springs until the ground pressure is equal. Also, the long coupling shaft may have too high sliding resistance on the LH side of the mowing unit due to dry tubes; grease the tubes of the long coupling shaft.

Summary

EU Declaration of Conformity

General Description and Preface

General Description

Provides an overview of the KM mowers, their functions, and design.

Preface

Introduction to the manual, usage advice, and dealer information.

Technical Specifications

Safety Guidance

Safety Suggestions and Instructions

Essential safety guidelines, warnings, and best practices for operation.

Danger Sticker Explanation Texts

Explains the meaning and importance of warning labels on the machine.

Assembly Instructions

General Assembly Notes

General guidelines and safety precautions for assembling the mower.

Assembling the Mower (KM 2800;3200;4000)

Step-by-step guide for assembling specific mower models from the crate.

Assembling the Mower (KM 4000 S)

Step-by-step guide for assembling the KM 4000S model from the crate.

Machine Setup and Adjustments

KM 2800;3200;4000 Assembly Details

Specific assembly steps for wheels and spring settings for KM 2800/3200/4000.

KM 4000 S Assembly Details

Specific assembly steps for wheels, arms, and springs for the KM 4000S.

Adjusting Transport Width (KM4000 S)

Instructions for adjusting the transport width of the KM4000S model.

Tractor Preparation and Connection

Preparing the Tractor

Steps to prepare the tractor for hitching the mower, including PTO and hydraulics.

Hydraulic Connection

Guide on connecting the mower's hydraulic lift cylinder to the tractor.

Attaching to the Tractor

Detailed steps for hitching the mower to the tractor's drawbar.

Coupling Shaft Procedures

Mounting the Coupling Shaft

Instructions for mounting the PTO coupling shaft correctly.

Shortening Procedure Coupling Shaft

Steps for shortening the PTO coupling shaft if necessary.

Mowing Operations and Adjustments

Cutting Height Adjustment

How to set and adjust the mower's cutting height.

Mowing Stony Fields

Advice and techniques for mowing in stony conditions using optional skids.

Ground Pressure Adjustment

How to set and adjust the ground pressure for optimal performance.

Mowing and Proper Techniques

Guidance on mowing procedures, speed, and turning for efficient operation.

Transport and Parking

Transport Position

Procedures for placing the mower in transport position for road use.

Operating Position

Procedures for moving the mower from transport to working position.

Transport and Road Use

Guidelines for transporting the mower on public roads and maximum speeds.

Parking the Mower

Safe procedures for parking the mower, including chocking and securing.

Maintenance and Lubrication

Lubrication Chart

Schedule and points for greasing and oiling machine components.

General Maintenance Guidelines

General safety and maintenance guidelines before working on the machine.

Exchanging Blades

Step-by-step guide for replacing worn or damaged mower blades.

Blade Stop on Cutter Disc

Important checks and procedures for the cutter disc blade stops.

Inspection of Bolts and Nuts

Regular checks and tightening of critical bolts and nuts.

Timing the Discs

Procedure for correctly timing the mower discs.

Hydraulic System

Checks and procedures for the mower's hydraulic system.

Accessories and Torques

Available Accessories

List of optional accessories for enhancing mower functionality.

Torque Specifications

Essential torque values for bolts and nuts during assembly and maintenance.

Troubleshooting

Trouble Shooting Table

A guide to identifying and solving common operational problems.
