2
Table of Contents
SECTION 1: GENERAL SAFETY INFORMATION ......................................2
1.01 Commonly Used Terms ...................................................2
SECTION 2: SPECIFICATIONS ................................................................3
2.01 CA411-3 Victor Cutting Attachment ................................3
2.02 Repair Parts List ..............................................................3
SECTION 3: SERVICE & REPAIR INSTRUCTIONS ...................................3
3.01 Recommended Tools & Supplies for Repair Procedures . 4
3.02 Cleaning Procedures .......................................................4
3.03 Control Valve Repair Kit ...................................................4
3.04 Cutting Lever ................................................................... 4
3.05 H.P. Oxy Valve Repair Kit ................................................. 5
3.06 Cone End Assembly Repair Kit ........................................5
3.07 400 Series Head Repair Kit ..............................................6
3.08 Gas Feed Tubes ...............................................................6
SECTION 4: TEST PROCEDURES ...........................................................7
4.01 Recommended Tools & Supplies for Test Procedures .....7
4.02 Leak Test the Gas Regulator ............................................ 7
4.03 Leak Testing the Torch .....................................................7
4.04 Flame Testing the Torch ...................................................7
SECTION 1: GENERAL SAFETY INFORMATION
Read and understand all safety and operating instructions provided before using this apparatus. RETAIN THESE INSTRUCTIONS IN A
READILY AVAILABLE LOCATION FOR FUTURE REFERENCE.
!
WARNING
DO NOT attempt to use this apparatus unless you are trained in its proper use or are under competent supervision. For your safety, practice
the safety and operating procedures described in this booklet every time you use the apparatus. Deviating from these procedures may result
in fire, explosion, property damage, and/or operator injury. If at any time the apparatus you are using does not perform in its usual manner, or
you have any difficulty in the use of the apparatus, STOP using it immediately. DO NOT use the apparatus until the problem has been corrected!
!
WARNING
Apparatus improperly operated, maintained or repaired can be dangerous. Some parts and accessories manufactured by others may fit
VICTOR apparatus but not conform to VICTOR’s exacting standards. For your own protection, specify and use ONLY VICTOR-made parts and
accessories with your VICTOR apparatus.
!
WARNING
Service or repair of apparatus should be performed only by a qualified repair technician capable of servicing gas apparatus in strict accordance
to applicable Part and Service bulletins for VICTOR manufactured products. Improper service repair, or modification of the product could result
in damage to the product or injury to the operator.
!
WARNING
WARNING: This product contains chemicals, including lead, known to the State of California to cause birth defects and other reproductive
harm. Wash hands after handling.
1.01 COMMONLY USED TERMS
BACKFIRE - The return of the flame into the torch, producing a popping sound. The flame will either extinguish or reignite at the tip.
SUSTAINED BACKFIRE - The return of the flame into the torch with continued burning within the torch. This condition may be accompanied
by a popping sound followed by a continuous hissing or whistling sound.
FLASHBACK - The return of the flame through the torch into the hose and even into the regulator. It may also reach the cylinder. This
condition could possibly cause an explosion in the system.
