Victor CUTMASTER 152 - Page 44

CUTMASTER 152
OPERATION Manual 0-4987
4T-12
Type Torch: SL100 with Exposed Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.06 1.5 9-8211 120 80 350 8.89 0.25 6.4 65 4.5 115 340 0.00 0.25 6.4
0.12 3.0 9-8211 124 80 300 7.62 0.25 6.4 65 4.5 115 340 0.10 0.25 6.4
0.188 4.8 9-8211 124 80 180 4.57 0.25 6.4 65 4.5 115 340 0.20 0.25 6.4
0.250 6.4 9-8211 128 80 110 2.79 0.25 6.4 65 4.5 115 340 0.30 0.25 6.4
0.375 9.5 9-8211 136 80 55 1.40 0.25 6.4 65 4.5 115 340 0.40 0.25 6.4
0.500 12.7 9-8211 139 80 38 0.97 0.25 6.4 65 4.5 115 340 0.60 0.25 6.4
0.625 15.9 9-8211 142 80 26 0.66 0.25 6.4 65 4.5 115 340 0.75 0.25 6.4
0.750 19.1 9-8211 145 80 24 0.61 0.25 6.4 65 4.5 115 340 NR NR NR
0.875 22.2 9-8211 153 80 10 0.25 0.25 6.4 65 4.5 115 340 NR NR NR
1.000 25.4 9-8211 162 80 6 0.15 0.25 6.4 65 4.5 115 340 NR NR NR
Type Torch: SL100 With Exposed Tip
Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4
9-8212 110 100 105 2.65 0.190 4.8 75 5.2 130 390
0.4
0.200 5.1
0.375 9.5
9-8212 117 100 70 1.75 0.190 4.8 75 5.2 130 390
0.5
0.200 5.1
0.500 12.7
9-8212 120 100 50 1.25 0.190 4.8 75 5.2 130 390
0.6
0.200 5.1
0.625 15.9
9-8212 125 100 35 0.90 0.190 4.8 75 5.2 130 390
1.0 0.200
5.1
0.750 19.0
9-8212 131 100 18 0.45 0.190 4.8 75 5.2 130 390
2.0 0.250
6.4
1.000 25.4
9-8212
135
100
10
0.25
0.190
4.8 75 5.2 130 390
NR NR NR
Type Torch: SL100 With Exposed Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250
6.4 9-8212
118
100
90
2.30
0.190
4.8 75 5.2 130 390
0.5 0.250
6.4
0.375
9.5 9-8212
122
100
55
1.40
0.190
4.8 75 5.2 130 390
0.8 0.250
6.4
0.500
12.7 9-8212
126
100
30
0.75
0.190
4.8 75 5.2 130 390
1.0 0.250
6.4
0.625
15.9 9-8212
133
100
20
0.50
0.190
4.8 75 5.2 130 390
1.5 0.250
6.4
0.750
19.0 9-8212
138
100
15
0.40
0.190
4.8 75 5.2 130 390
NR NR
NR
1.000
25.4 9-8212
139
100
10
0.25
0.190
4.8 75 5.2 130 390
NR NR
NR
Type Torch: SL100 with Exposed Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4 9-8212 108 100 120 3.05 0.190 4.8 65 4.5 120 360 0.2 0.225 5.7
0.375 9.5 9-8212 117 100 65 1.65 0.190 4.8 65 4.5 120 360 0.4 0.225 5.7
0.500 12.7 9-8212 120 100 45 1.15 0.190 4.8 65 4.5 120 360 0.5 0.225 5.7
0.625 15.9 9-8212 125 100 30 0.75 0.190 4.8 65 4.5 120 360 0.8 0.225 5.7
0.750 19.0 9-8212 131 100 25 0.65 0.190 4.8 65 4.5 120 360 1.0 0.225 5.7
1.000
25.4 9-8212
140
100
10
0.25
0.190
4.8 65 4.5 120 360
NR NR
NR
