CUTMASTER 52
OPERATION Manual 0-4961
4T-12
Type Torch: SL60 With Exposed Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage
Speed (Per
Minute)
Standoff
Plasma Gas
Press
Flow (CFH) Pierce
Pierce
Height
Inches
mm
(Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi* bar Plasma Total**
Delay
(Sec)
Inches mm
0.060 1.5 9-8210 110 60 440 11.18 0.25 6.4 75 5.2 90 245 0.00 0.25 6.4
0.075 1.9 9-8210 110 60 440 11.18 0.25 6.4 75 5.2 90 245 0.10 0.25 6.4
0.120 3.0 9-8210 116 60 250 6.35 0.25 6.4 75 5.2 90 245 0.10 0.25 6.4
0.188 3.4 9-8210 116 60 170 4.32 0.25 6.4 75 5.2 90 245 0.20 0.25 6.4
0.250 6.4 9-8210 132 60 85 2.16 0.25 6.4 75 5.2 90 245 0.30 0.25 6.4
0.375 9.5 9-8210 140 60 45 1.14 0.25 6.4 75 5.2 90 245 0.50 0.25 6.4
0.500
12.7 9-8210 143 60 30 0.76 0.25 6.4 75 5.2 90 245 0.80 0.25 6.4
0.625 15.9 9-8210 145 60 20 0.51 0.25 6.4 75 5.2 90 245 NR NR NR
0.750 19.1 9-8210 145 60 18 0.46 0.25 6.4 75 5.2 90 245 NR NR NR
NOTE
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m leads, refer to
Section "Set Operating Pressure" on page 4-2.
** Total flow rate includes plasma and secondary gas flow.
