Victor Cutmaster 52 - Page 47

CUTMASTER 52
Manual 0-4961 OPERATION
4T-15
Type Torch: SL60 With Shielded Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage
Speed (Per
Minute)
Standoff
Plasma Gas
Press
Flow (CFH) Pierce
Pierce
Height
Inches
mm
(Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi* bar Plasma Total**
Delay
(Sec)
Inches mm
0.060 1.5 9-8210 105 60 350 8.89 0.13 3.2 75 5.2 90 245 0.00 0.20 5.1
0.075 1.9 9-8210 110 60 350 8.89 0.13 3.2 75 5.2 90 245 0.10 0.20 5.1
0.120 3.0 9-8210 110 60 275 6.99 0.13 3.2 75 5.2 90 245 0.10 0.20 5.1
0.188 3.4 9-8210 122 60 140 3.56 0.13 3.2 75 5.2 90 245 0.20 0.20 5.1
0.250 6.4 9-8210 134 60 80 2.03 0.19 4.8 75 5.2 90 245 0.30 0.20 5.1
0.375 9.5 9-8210 140 60 45 1.14 0.19 4.8 75 5.2 90 245 0.50 0.20 5.1
0.500
12.7 9-8210 144 60 26 0.66 0.19 4.8 75 5.2 90 245 0.80 0.20 5.1
0.625 15.9 9-8210 145 60 19 0.48 0.19 4.8 75 5.2 90 245 NR NR NR
0.750 19.1 9-8210 150 60 15 0.38 0.19 4.8 75 5.2 90 245 NR NR NR
NOTE
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m leads, refer to
Section "Set Operating Pressure" on page 4-2.
** Total flow rate includes plasma and secondary gas flow.
